E-Flex
4Stage is a 4-circuit stage power controller designed for pipe mounted stage lighting
control. E-Flex 4Stage panels are
installed throughout a theater with single or multiple panels at each lighting
position: front of house catwalk, side tormentors, and stage electrics. Standard wall mount E-Flex 4 and 8 circuit panels can be
used for lighting not requiring pipe mounting or direct fixture
connections and house lighting control.
Each
E4Stage includes 4 electronic ballast latching relays with a PowerCon or Edison receptacle
per relay for direct power connection to the pipe mounted fixtures. The relays are rated 16A for electronic
ballast loads (LEDs) and 20A for most other loads. Standard power input to the
panel is terminals with an optional factory installed 9-wire, 12 AWG SO cable
drop in custom lengths or a 3-phase power cord.
E-Flex
4Stage are DMX512 controlled and support RDM control to program DMX
start addressing.
DMX in/thru connectors are mounted to the panel for direct DMX control
output to the fixtures. Models with W-DMX wireless control are also available.
User
configuration of the DMX ON/OFF threshold and DMX loss response settings are
programmable.
